Monorail Beam Design
Analysis and design of underhung monorail beams per AISC 9th Edition ASD and CMAA Specification No. 74 (2004).
⤢
Key features
- <b>Multi-section support</b>: W, H (built-up), I, UB/UC, HE/IPE
- Bending including <b>warping stress</b>
- <b>Bottom-flange checks per CMAA No. 74</b>
- Includes the <b>overhang</b> (Lo, Lbo, Cbo)
- Includes vertical impact and horizontal load factors
- Deflection check Δmax
- Save/open project
System requirements
Windows
